(Performance data
should have been similar to P-38G Model)
CLASSIFICATION
CLASS :
PHOTO-RECONNAISSANCE AIRCRAFT
COUNTRY OF ORIGIN :
UNITED STATES
MANUFACTURER :
Lockheed Aircraft Corporation
FIRST FLIGHT :
1942
SERVICE DELIVERY :
AUGUST 1942
NUMBER BUILT :
180 (Converted from
P-38G Models)
SPECIFICATION
SPAN :
52 ft 0 in (15.84 m)
LENGTH :
37 ft 10 in (11.53 m)
HEIGHT :
12 ft 10 in (3.91 m)
WING AREA :
327.5 sq ft (30.42 m sq)
WING LOADING :
---
POWER LOADING :
---
ASPECT RATIO :
---
WEIGHT EMPTY :
12,200 lbs (5534 kg)
WEIGHT LOADED :
15,800 lbs (7167 kg)
WEIGHT MAX :
19,800 lbs (8981 kg)
ARMAMENT :
NONE
PAYLOAD :
4 x K-17 Cameras;
POWER PLANT :
2 x Allison V-1710-51/55 Turbo-Supercharged Piston Engines, Rated
at 1,325 hp each
CREW :
1 - Pilot
PERFORMANCE
MAXIMUM SPEED :
400 mph (644 km/h) at 25,000 ft (7620 m)
CRUISING SPEED :
340 mph (547 km/h)
LANDING SPEED :
89 mph (143 km/h)
CLIMB RATE :
To 20,000 ft (6096 m) in 8.5 min
RANGE :
275 miles (443 km); 2,400 miles (3862 km) Max
SERVICE CEILING :
39,000 ft (11887 m)
REFERENCES
Angelucci, Enzo; Bowers, Peter. The American Fighter - The Definitive Guide To American Fighter Aircraft From 1917 to the Present. New York: Orion Books. 1985. ISBN 0-517-56588-9.
